TypeORM: search in relationships (ft. NestJS)

🤔 Why?

Because I didn’t want to perform a full search once I brought all the records. Since SQL is really optimized for queries. For this case, I wanted to filter some records based on their relationship attributes.

I’ll use a simple test case.

💡 First, we need two TypeORM entities

For the most simple of cases, let’s suppose we have two classes. A Pet and an Owner. A Pet will belong to only one Owner. Both entities live in the same folder.

// ./entities/pet.ts
import { Column, Entity, JoinColumn, ManyToOne, PrimaryGeneratedColumn } from "typeorm";
import { Owner } from "./owner";

@Entity()
export class Pet {
  @PrimaryGeneratedColumn()
  id: number;

  @Column({ name: "owner_id" })
  ownerId: number;

  @ManyToOne(() => Owner)
  @JoinColumn({ name: "owner_id" })
  owner: Owner;
}

And

// ./entities/owner.ts
import { Column, Entity, JoinColumn, OneToMany, PrimaryGeneratedColumn } from "typeorm";
import { Pet } from "./pet";

@Entity()
export class Owner {
  @PrimaryGeneratedColumn()
  id: number;

  @Column({ name: "first_name" })
  firstName: string;

  @Column({ name: "last_name" })
  lastName: string;

  @OneToMany(() => Pet, () => Owner)
  @JoinColumn({ name: "owner_id" })
  pets: Pet[];
}

🔨 Creating the method for the controller

We will use NestJS. A simple NestJS controller seems like the following example.

@Controller("pets")
export default class AppController {
  @Get()
  async search() {
    // TODO: Implement search
  }
}

As you see here. The URL for the search will be /pets/search

🚛 Using Repositories

This is the method Typescript friendly. I prefer this since I’ll have type validation if I update any field in the future.

// ./app.ts
import { Controller, Get, Query } from "@nestjs/common";
import { Pet } from "./entities/pet";
import { FindManyOptions, FindOptionsWhere, Like, Repository } from "typeorm";
import { InjectRepository } from "@nestjs/typeorm";

@Controller("pets")
export default class AppController {
  constructor(@InjectRepository(Pet) private petRepository: Repository<Pet>) {}

  @Get("/repository")
  async searchUsingRepository(@Query("search") search?: string) {
    // By default we load the relationship in the default options
    const options: FindManyOptions<Pet> = { relations: { owner: true } };

    if (search?.length) {
      // if search request query param was sent. Create an array of words
      const searchFormattedText = search.trim().split(" ");
      const where: FindOptionsWhere<Pet>[] = [];

      // Create OR WHERE queries by each word into first and last name
      for (const word of searchFormattedText) {
        where.push({ owner: { firstName: Like(`%${word}%`) } });
        where.push({ owner: { lastName: Like(`%${word}%`) } });
      }

      // Adding those where to options
      options.where = where;
    }

    const pets = await this.petRepository.find(options);

    return { pets };
  }
}

It will produce the following query

SELECT `Pet`.`id`                    AS `Pet_id`,
       `Pet`.`owner_id`              AS `Pet_owner_id`,
       `Pet__Pet_owner`.`id`         AS `Pet__Pet_owner_id`,
       `Pet__Pet_owner`.`first_name` AS `Pet__Pet_owner_first_name`,
       `Pet__Pet_owner`.`last_name`  AS `Pet__Pet_owner_last_name`
FROM `pet` `Pet`
         INNER JOIN `owner` `Pet__Pet_owner` ON `Pet__Pet_owner`.`id` = `Pet`.`owner_id`
WHERE ((`Pet__Pet_owner`.`first_name` LIKE ?) OR (`Pet__Pet_owner`.`last_name` LIKE ?))

🚛 Using Query Builder from repositories

This method is more close to SQL. Useful if you’re more comfortable with it.

// ./app.ts
import { Controller, Get, Query } from "@nestjs/common";
import { Pet } from "./entities/pet";
import { Brackets, SelectQueryBuilder, Like, Repository } from "typeorm";
import { InjectRepository } from "@nestjs/typeorm";

@Controller("pets")
export default class AppController {
  constructor(@InjectRepository(Pet) private petRepository: Repository<Pet>) {}

  @Get("/querybuilder")
  async searchUsingQueryBuilder(@Query("search") search?: string) {
    // This is how we load relationships here
    let query = this.petRepository.createQueryBuilder("p").innerJoinAndSelect("p.owner", "o");

    if (search?.length) {
      // By default we load relationship in the default options
      const searchFormattedText = search.trim().split(" ");

      // With query builder we specify the AND or OR queries
      // Brackets is a way to group queries within a ( )
      query = query.andWhere(
        new Brackets((queryPart: SelectQueryBuilder<Pet>) => {
          for (const word of searchFormattedText) {
            queryPart.orWhere("o.first_name like :firstName", {
              firstName: `%${word}%`,
            });
            queryPart.orWhere("o.last_name like :lastName", {
              lastName: `%${word}%`,
            });
          }
        }),
      );
    }

    const pets = await query.getMany();

    return { pets };
  }
}

The query for the function above will result as

SELECT `p`.`id`         AS `p_id`,
       `p`.`owner_id`   AS `p_owner_id`,
       `o`.`id`         AS `o_id`,
       `o`.`first_name` AS `o_first_name`,
       `o`.`last_name`  AS `o_last_name`
FROM `pet` `p`
         INNER JOIN `owner` `o` ON `o`.`id` = `p`.`owner_id`
WHERE (`o`.`first_name` like ? OR `o`.`last_name` like ?)

⭐ Final result

This is the final controller. I’ll add a docker-compose file if you want to try it by yourself. Also, there is a /fake method to create records if you want to test the search.

Remember, this is ONLY the main controller. Check my FULL demo on Github here

// ./app.ts
import { Controller, Get, Post, Query } from "@nestjs/common";
import { Pet } from "./entities/pet";
import {
  Brackets,
  FindManyOptions,
  FindOptionsWhere,
  InsertResult,
  Like,
  Repository,
  SelectQueryBuilder,
} from "typeorm";
import { InjectRepository } from "@nestjs/typeorm";
import { Owner } from "./entities/owner";

@Controller("pets")
export class AppController {
  constructor(
    @InjectRepository(Pet) private petRepository: Repository<Pet>,
    @InjectRepository(Owner) private ownerRepository: Repository<Owner>,
  ) {}

  @Get("/repository")
  async searchUsingRepository(@Query("search") search?: string) {
    const options: FindManyOptions<Pet> = { relations: { owner: true } };

    if (search?.length) {
      const searchFormattedText = search.trim().split(" ");
      const where: FindOptionsWhere<Pet>[] = [];

      for (const word of searchFormattedText) {
        where.push({ owner: { firstName: Like(`%${word}%`) } });
        where.push({ owner: { lastName: Like(`%${word}%`) } });
      }

      options.where = where;
    }

    const pets = await this.petRepository.find(options);

    return { pets };
  }

  @Get("/querybuilder")
  async searchUsingQueryBuilder(@Query("search") search?: string) {
    let query = this.petRepository.createQueryBuilder("p").innerJoinAndSelect("p.owner", "o");

    if (search?.length) {
      const searchFormattedText = search.trim().split(" ");

      query = query.andWhere(
        new Brackets((queryPart: SelectQueryBuilder<Pet>) => {
          for (const word of searchFormattedText) {
            queryPart.orWhere("o.first_name like :firstName", {
              firstName: `%${word}%`,
            });
            queryPart.orWhere("o.last_name like :lastName", {
              lastName: `%${word}%`,
            });
          }
        }),
      );
    }

    const pets = await query.getMany();

    return { pets };
  }

  @Post("/fakes")
  async fakes() {
    const ownerPromises: Promise<InsertResult>[] = [];
    let ownerCount = await this.ownerRepository.count();

    for (let i = ownerCount + 1; i <= ownerCount + 100; i++) {
      const owner = new Owner();
      owner.firstName = `first_${i} name_${i}`;
      owner.lastName = `last_${i} name_${i}`;
      ownerPromises.push(this.ownerRepository.insert(owner));
    }

    await Promise.all(ownerPromises);

    ownerCount = await this.ownerRepository.count();

    const petPromises: Promise<InsertResult>[] = [];
    let petCount = await this.petRepository.count();

    for (let j = petCount + 1; j <= petCount + 100; j++) {
      const pet = new Pet();
      pet.ownerId = this.#randomInteger(1, ownerCount);
      petPromises.push(this.petRepository.insert(pet));
    }

    await Promise.all(petPromises);

    petCount = await this.petRepository.count();

    return { ownerCount, petCount };
  }

  #randomInteger(min: number, max: number) {
    min = Math.ceil(min);
    max = Math.floor(max);
    return Math.floor(Math.random() * (max - min) + min);
  }
}
